RSFK four series gear reducers, hard tooth surface helical gear reducers, and customized models for motor machining are complete

The characteristics of the four major series:
Performance characteristics of R series reducer:
1. The R series gear reducer products have low noise, high energy saving, and low vibration;
2. Using forged steel material, steel cast iron box body, and high-frequency heat treatment on the gear surface;
3. After precision machining to ensure the parallelism of the shaft and the requirements for positioning bearings, the reducer of the helical gear transmission assembly is equipped with various types of motors, combined into electromechanical components to ensure the quality characteristics of the product;
4. Made in accordance with international technical requirements, it has a high technological content;
5. Space saving, reliable and durable, high overload capacity, power up to 160KW;
6. Low energy consumption, superior performance, and gearbox efficiency of over 95%;
7. The R series can withstand high radial loads.
R series reducer model classification:
R-type:
R17、R27、R37、R47、R57、R67、R77、R87、R97、R107R137、R147、R167
RF type:
RF17、RF27、RF37、RF47、RF57、RF67、RF77、RF87、RF91、RF107、RF137、RF147、RF167
RX type:
RX57、RX67、RX77、RX87、RX97、RX107、RX127、RX157
RXF type:
RXF37、RXF57、RXF67、RXF77、RXF87、RXF97、RXF107RXF127、RXF157
Technical parameters of R series reducer:
Speed ratio range: R basic type 3.33-289.74, RX type 13-8.65, R/R combination type can reach 27001
Torque range: R basic type 85~18000 Nm, RX type 20~1680 Nm
Power range: R basic type 0.18-160 kW, RX type 018~132kW
Performance characteristics of F-series reducer:
1. Parallel output, compact structure, high torque transmission, smooth operation, low noise, long lifespan.
2. Installation methods: base installation, hollow shaft installation, flange installation, torsion arm installation, small flange installation
3. The basic type has the same rotation direction for the second stage input and output, but for the third stage with opposite F/R combinations, please consult separately.
4. Output mode: hollow shaft output or solid shaft output.
5. Average efficiency: Level 2 96%, Level 3 94%, F/R combination average efficiency of 85%
The products are widely used in light industry, food, beer and beverage, chemical industry, escalators, automated warehousing equipment, building materials machinery, steel metallurgy, environmental protection, power plants, coal, mining, papermaking, artificial boards, automobiles, ports (airports, docks) and other fields.
F series reducer model classification:
F-type:
F37、F47、F57、F67、F77、F87、F97、F107、F127、F157
