Page 134 - China WGT Coupling products wgt.asia wgt.net.cn

尺寸(mm)
回转直径 额定转矩 疲劳转矩
轴线折角 Size (mm) 转动惯量
turn around Rated Fatigue 重量
型号 Axis Moment of
diameter torque Torque Weight
Type Chamfer β inertia
D Tn Tn (kg)
(。) d2 B (kg.m²)
(mm) (KN.m) (KN.m) L DI JsH Lm n-d k t g
(H7) (b9)
SWC180WD 180 12. 5 6.3 ≤25 440 155 105 l10 8~17 17 5 0.145 52

SWC225WD 225 40 20 ≤15 480 196 135 120 8~17 20 5 32 9 0.355 82

SWC250WD 250 63 31.5 ≤15 560 218 150 140 8~19 25 6 40 12.5 0.831 127

SWC285WD 285 90 45 ≤15 640 245 170 160 8~21 27 7 40 15 1.715 189

SWC315WD 315 125 63 ≤15 720 280 185 180 10~23 32 8 40 15 2.28 270

SWC350WD 350 180 90 ≤15 776 310 210 194 10~23 35 8 50 16 4.971 370

SWC390WD 390 250 125 ≤15 860 345 235 215 10~25 40 8 70 18 8.229 524

SWC440WD 440 355 180 ≤15 1040 390 255 260 16~28 42 10 80 20 15.32 798

SWC490WD 490 500 250 ≤15 1080 435 275 270 16~31 47 12 90 22.5 25.74 1055

SWC550WD 550 710 355 ≤15 1220 492 320 305 16~31 50 12 100 22.5 46.78 1524

SWC620WD 520 1000 500 ≤15 1360 555 380 340 10~38 55 12 100 25 88.76 2120

注:1.Tr~在交变负荷下按疲劳强度所允许的转矩。
Note: 1.Tr ~ Allowable torque according to fatigue strength under alternating load.
