转动惯量I 重量G
轴线折角
尺寸(mm) Moment of inertia I Weight
回转直径 额定转矩 疲劳转矩 Axis
伸缩量Ls Size (mm)
Swing Rated Fatigue chamfer
型号 Expansion (kg.m) (kg)
diameter torque torque
Type amount Ls
D Tn TF 增长 增长
mm β D1 D2 B
mm KN.m KN.m Lmin D3 Lm n-d k t g Lmin increase Lmin increase
° (js11) (H7) (h9) 100mm 100 mm
SWC180DH1 75 650 0.165 58

SWC180DH2 180 12.5 6.3 ≤25 55 600 155 105 1114 110 8~17 17 5 0.162 0.007 56 2.8

SWC180DH3 40 550 1 0.16 52

SWC225DH1 85 710 0.415 95
225 40 20 ≤15 196 135 152 120 8~17 20 5 32| 9 0.0234 4.9
SWC225DH2 70 640 0.397 92

SWC250DH1 100 795 0.9 148
250 63 31.5 ≤15 218 150 168 140 8~19 25 6 40 12.5 0.0277 5.3

SWC250DH2 70 735 0.885 136

SWC285DH1 120 950 1.8261 229

285 90 45 ≤15 245 170 194 160 8~21 27 7 40 15 0.051 6.3
SWC285DH2 80 880 1.801 221

SWC315DH1 130 1070 3.331 346
315 125 63 ≤15 280 185 219 180 10~23 32 8 40 15 0.0795 8
SWC315DH2 90 980 3.163 334

SWC350DH1 140 1170 6.215 508
350 180 90 ≤15 310 210 267 194 10~23 35 8 50 16 0.2219 15

SWC350DH2 90 1070 5.824 485

SWC390DH1 150 1300 11.125 655

390 250 125 ≤15 345 235 267 215 10~25 40 8 70 18 0.2219 15
SWC390DH2 90 1200 10.763 600
